Introdução
Thank you for choosing the EXERPEUTIC 675 XLS Bluetooth Smart Technology Folding Upright Exercise Bike. This manual provides essential information for the safe assembly, operation, and maintenance of your exercise bike. Please read all instructions carefully before use and retain this manual for future reference.
Informações importantes de segurança
- Consulte seu médico antes de iniciar qualquer programa de exercícios.
- Leia todas as instruções deste manual antes de usar o equipamento.
- Mantenha crianças e animais de estimação longe do equipamento durante o uso.
- Place the exercise bike on a solid, level surface with adequate clearance around it.
- Inspecione o equipamento quanto a peças desgastadas ou soltas antes de cada utilização. Não utilize se estiver danificado.
- Use roupas e calçados adequados para exercícios.
- Não exceda a capacidade máxima de peso do usuário de 181 kg (400 lbs).
- Adjust the seat and handlebars to a comfortable and safe position before exercising.
- Pare de se exercitar imediatamente se sentir fraqueza, tontura ou dor.
Conteúdo da embalagem
Verifique se todos os componentes estão presentes antes de iniciar a montagem. Caso alguma peça esteja faltando ou danificada, entre em contato com o suporte ao cliente.
- Main Bike Frame
- Stabilizer Bars (Front and Rear)
- Pedais (esquerdo e direito)
- Assento e espigão
- Handlebar and Handlebar Post
- LCD Display Console
- Kit de ferragens (parafusos, arruelas, porcas, ferramentas)
- Manual do usuário
Configuração e montagem
Follow these steps to assemble your EXERPEUTIC 675 XLS exercise bike. It is recommended to have two people for assembly.
Step 1: Attach Stabilizer Bars
Attach the front and rear stabilizer bars to the main frame using the provided bolts and washers. Ensure they are securely tightened.
Image: The EXERPEUTIC 675 XLS exercise bike shown from the side, illustrating the main frame with the front and rear stabilizer bars securely attached to the base.
Etapa 2: Instale os pedais
Identify the left (L) and right (R) pedals. The left pedal tightens counter-clockwise, and the right pedal tightens clockwise. Thread them carefully into the crank arms and tighten with a wrench.
Imagem: Um lado view of the EXERPEUTIC 675 XLS exercise bike, highlighting the installed pedals on the crank arms, ready for use.
Step 3: Attach Seat and Handlebar Posts
Insert the seat post into the main frame and secure it at your desired height using the adjustment knob. Similarly, insert the handlebar post and attach the handlebar, securing all components firmly.
Step 4: Connect Console
Connect the sensor wires from the main frame to the LCD display console. Mount the console onto the handlebar post. Ensure all connections are secure.
Instruções de operação
Ajustando o assento
To adjust the seat height, loosen the adjustment knob on the seat post, slide the seat to the desired height, and re-tighten the knob securely. Ensure your knee has a slight bend at the bottom of the pedal stroke.
Utilizando o console de exibição LCD
The LCD console displays time, speed, distance, calories, and pulse. Use the MODE button to cycle through display functions. The SCAN function automatically rotates through all metrics.
Resistência de ajuste
The bike features a 16-level magnetic tension control system. Turn the resistance knob located below the handlebars clockwise to increase resistance and counter-clockwise to decrease it.
Bluetooth Connectivity and MyCloudFitness App
Your EXERPEUTIC 675 XLS bike is equipped with Bluetooth Smart Technology. Download the MyCloudFitness App from your device's app store. Enable Bluetooth on your device and open the app to connect to your bike. The app allows access to personalized workout programs, scenic routes, and tracks your workout data.
Folding the Bike for Storage
To fold the bike, loosen the folding knob located on the main frame. Carefully fold the bike until it locks into the upright storage position. Ensure it is stable before moving. The integrated transport wheels allow for easy relocation.
Image: The EXERPEUTIC 675 XLS exercise bike shown in its compact, folded position, demonstrating its space-saving design for storage.
Image: A user demonstrating the folding process of the EXERPEUTIC 675 XLS exercise bike, preparing it for compact storage or transport.
Manutenção
- Limpeza: Limpe a bicicleta com anúncioamp Limpe com um pano após cada uso para remover o suor e a poeira. Evite produtos de limpeza abrasivos.
- Inspeção: Verifique regularmente se todos os parafusos, porcas e peças móveis estão apertados e se apresentam desgaste. Aperte quaisquer fixadores soltos.
- Lubrificação: No regular lubrication is required for the magnetic resistance system.
- Armazenar: Store the bike in a cool, dry place away from direct sunlight and extreme temperatures.
Solução de problemas
| Problema | Possível causa | Solução |
|---|---|---|
| Nenhuma exibição no console | As pilhas estão descarregadas ou instaladas incorretamente. Conexão solta. | Replace batteries (if applicable) or ensure they are installed correctly. Check all wire connections to the console. |
| Inaccurate readings (speed, distance) | Sensor wire loose or damaged. | Check the sensor wire connection from the main frame to the console. Ensure it is fully plugged in. |
| A resistência não muda | Cabo de resistência desconectado ou danificado. | Inspect the resistance cable connection to the resistance knob and the magnetic mechanism. Contact customer support if damaged. |
| A bicicleta está instável ou oscila. | Stabilizer bars not tightened. Uneven surface. | Ensure all bolts on the stabilizer bars are securely tightened. Place the bike on a level surface. Adjust leveling caps if present. |
Especificações
- Modelo: EXERPEUTIC 675 XLS
- Número do modelo do item: 4104
- Capacidade Máxima de Peso: 400 libras (181 kg)
- User Height Capacity: 5'1" a 6'5" (155 cm a 196 cm)
- Sistema de resistência: 16 Level Magnetic Tension Control
- Tipo de exibição: LCD
- Conectividade: Bluetooth Smart Technology (MyCloudFitness App compatible)
- Material da estrutura: Aço
- Características: Adjustable Seat, Foldable, Heavy Duty
- Dimensões do produto (desdobrado): 99.06 x 67.06 x 122.94 cm (C x L x A)
- Peso do produto: 28.58 kg
- Fonte de energia: Corded Electric (for console, if applicable, or batteries)
Garantia e Suporte
For warranty information, please refer to the specific warranty card included with your product or contact the manufacturer directly. The manufacturer is Paradigm Health and Wellness.
If you require technical assistance or have questions regarding your EXERPEUTIC 675 XLS exercise bike, please contact EXERPEUTIC customer support. Contact details are typically found in the included manual or on the manufacturer's official website.
