1. Introdução
Thank you for choosing the AIRHOT TM401 Foldable Treadmill. This manual provides essential information for the safe and effective use, assembly, operation, and maintenance of your new fitness equipment. Please read this manual thoroughly before initial use and retain it for future reference.
2. Informações de segurança
Para garantir sua segurança e prolongar a vida útil da sua esteira, observe as seguintes precauções:
- Consulte um médico antes de iniciar qualquer programa de exercícios, especialmente se você tiver problemas de saúde preexistentes.
- Use sempre calçado desportivo apropriado ao utilizar a passadeira.
- Ensure the area around the treadmill is clear of obstructions before and during use.
- Mantenha crianças e animais de estimação longe da esteira durante a operação.
- Do not place a mat or any other object under the front motor cover during operation. This can obstruct heat dissipation, potentially leading to motor damage and shortening the treadmill's lifespan.
- Do not exceed the maximum user weight capacity of 120 kg.
- Use the emergency stop feature if you feel unwell or lose balance.
3. Produto acabadoview
The AIRHOT TM401 is a versatile and compact foldable treadmill designed for home use. It features a quiet motor, a wide running belt, and multiple exercise modes to suit various fitness needs.
Principais características:
- Design dobrável que economiza espaço: Folds in one step for convenient storage, with a thickness of approximately 15 cm.
- Wide Running Belt: A 40 cm wide, 5-layer anti-slip running belt ensures a safe and comfortable workout experience.
- Funcionalidade 2 em 1: Supports both jogging/brisk walking (with handrail) and walking under a desk (handrail folded).
- Quiet 2.25 HP Motor: Provides smooth operation with minimal noise, allowing for undisturbed workouts.
- Multi-functional LED Display: Tracks real-time data including speed, distance, time, and calories burned.
- Faixa de velocidade: Adjustable from 1 km/h to 10 km/h.
Componentes:
Familiarize yourself with the main components of your treadmill:
- Correia de corrida
- Motor Cover (front)
- Handrail/Armrests
- Painel de controle com display LED
- Controle remoto
- Chave de parada de emergência
Figura 1: Illustration of the 5-layer running belt, designed for comfort and safety.
Figura 2: The control panel with LED display and the included remote control for easy operation.
4. Configuração
Desembalagem:
- Retire cuidadosamente a esteira da embalagem.
- Remove all packing materials and inspect the treadmill for any damage. If damaged, contact customer support immediately.
- Certifique-se de que todos os componentes listados na lista de embalagem estejam presentes.
Desdobrando a esteira:
Figura 3: The treadmill can be easily folded for compact storage, reducing its height to approximately 15 cm.
- Coloque a esteira em uma superfície plana e estável.
- Gently lift the handrail assembly until it locks into the upright position. Ensure it is securely locked before use.
- Conecte o cabo de alimentação a uma tomada elétrica aterrada.
Colocação:
Choose a location with sufficient space around the treadmill for safe operation. Avoid placing it near water or in direct sunlight. Ensure the floor is level.
5. Instruções de operação
Ligando:
- Conecte o cabo de alimentação a uma tomada adequada.
- Insert the emergency stop key into its designated slot on the control panel. The display will illuminate.
Iniciando um treino:
- Suba na esteira, segurando nos corrimãos para manter o equilíbrio.
- Press the START button on the control panel or remote control. The treadmill will begin at a low speed (e.g., 1 km/h) after a short countdown.
- Adjust the speed using the '+' and '-' buttons on the control panel or remote control.
Modos 2 em 1:
Figura 4: The treadmill supports both walking (1.0-6.0 km/h) with the handrail folded and running (6.0-10.0 km/h) with the handrail upright.
- Modo caminhada (1.0-6.0 km/h): For walking, the handrail can be folded down, allowing the treadmill to be used under a standing desk.
- Modo de corrida (6.0-10.0 km/h): For jogging or running, ensure the handrail is securely locked in the upright position.
Usando o controle remoto:
The remote control allows for convenient adjustment of speed and mode. The 'M' button can be used to set customized target goals for your workout.
Monitorando seu treino:
The LED display shows your current speed, distance covered, workout duration, and estimated calories burned. This data helps you track your progress and achieve your fitness goals.
Parando a esteira:
- Press the STOP button on the control panel or remote control. The treadmill will gradually slow down and stop.
- For emergency stops, pull the emergency stop key from its slot. The treadmill will immediately cease operation.
6. Manutenção
Limpeza:
Limpe regularmente a esteira com um pano úmido.amp Use um pano para remover poeira e suor. Não utilize produtos de limpeza abrasivos ou solventes.
Lubrificação:
The running belt requires periodic lubrication to ensure smooth operation and prevent wear. Refer to the specific lubrication instructions provided with your treadmill or contact customer support for guidance.
Tensão e alinhamento da correia:
Check the running belt tension and alignment periodically. If the belt feels loose or is drifting to one side, consult the detailed instructions in the full product manual or contact customer support for adjustment procedures.
Armazenar:
Figura 5: The treadmill operates quietly at 45dB, making it suitable for use in shared spaces or while working.
When not in use, fold the treadmill for compact storage. Store it in a dry, cool place away from direct sunlight and moisture. The compact design allows it to be stored under a sofa, bed, or against a wall.
7. Solução De Problemas
If you encounter any issues with your AIRHOT TM401 treadmill, please refer to the following common problems and solutions:
| Problema | Possível causa | Solução |
|---|---|---|
| A esteira não liga. | Power cord not plugged in, emergency key not inserted, power switch off, circuit breaker tripped. | Ensure power cord is securely plugged in. Insert emergency stop key. Check the main power switch. Reset circuit breaker if necessary. |
| A esteira escorrega ou hesita. | Belt too loose, insufficient lubrication, worn belt. | Adjust belt tension (refer to full manual). Apply lubricant as per instructions. If worn, contact customer support for replacement. |
| Ruído incomum durante a operação | Componentes soltos, problema no motor, atrito na correia. | Check for loose screws and tighten. Ensure proper lubrication. If noise persists, discontinue use and contact customer support. |
| O visor não está funcionando corretamente. | Loose cable connection, electronic malfunction. | Check all cable connections. If the issue persists, contact customer support. |
For problems not listed here or if solutions do not resolve the issue, please contact AIRHOT customer support.
8. Especificações
| Recurso | Especificação |
|---|---|
| Número do modelo | TM401 (Product Type Number: TM400-200-800) |
| Velocidade Máxima | 10 km/h |
| Capacidade de carga | 120 kg |
| Dimensões do produto (C x L x A) | 135 x 65 x 15 cm (dobrado) |
| Peso do produto | 26 kg |
| Potência do motor | 2.25 HP |
| Material | Liga de aço |
| Cor | Branco |
| Usuário de destino | Adulto |
9. Garantia e Suporte
AIRHOT is committed to providing high-quality fitness products and excellent customer service. We offer a 100% satisfaction guarantee.
Suporte ao cliente:
If you have any questions, concerns, or require assistance with your AIRHOT TM401 treadmill, please do not hesitate to contact us via email. Our professional customer service team aims to respond to all inquiries within 24 hours.
For contact information, please refer to the product packaging or the official AIRHOT website.
