Manual do Usuário dos Fones de Ouvido de Condução Óssea LOBKIN X18

Introdução

Thank you for choosing the LOBKIN X18 Bone Conduction Headphones. These innovative open-ear headphones are designed to provide a comfortable and safe audio experience for various activities, including swimming, running, cycling, and daily use. Featuring IPX8 waterproofing, Bluetooth 5.4 connectivity, and a built-in 32GB MP3 player, the X18 allows you to enjoy your music anytime, anywhere, while remaining aware of your surroundings.

O que está na caixa

• LOBKIN X18 Bone Conduction Headphones
• Cabo de carregamento magnético
• Manual do usuário
• Pair of Earplugs
• Alça ajustável
• Cartão de garantia

Image: All items included in the LOBKIN X18 package.

Principais características

Design de ouvido aberto

The LOBKIN X18 transmits clear sound directly through the skull to the inner ear, minimizing sound leakage. Its open-ear design reduces pressure on the ears and helps prevent hearing damage, allowing you to stay aware of your surroundings.

Image: The open-ear design ensures comfort and awareness.

IPX8 Waterproof & 32GB MP3 Mode

With an IPX8 waterproof rating and 32GB of internal memory, these headphones transform into an MP3 player for underwater use. This feature ensures uninterrupted music playback during swimming without concerns about Bluetooth signal loss in water.

Image: Enjoy music underwater with IPX8 waterproofing and built-in 32GB MP3 storage.

Conectividade Bluetooth 5.4

Equipped with the latest Bluetooth 5.4 technology, the X18 provides a stable connection, lower latency, and faster data transfer for superior audio quality and detail.

Image: Bluetooth 5.4 ensures a stable and fast connection for all your activities.

Confortável e leve

The ultra-lightweight design, weighing only 27g, features skin-friendly, non-slip, soft silicone. The inner titanium alloy neckband offers elasticity and durability, ensuring a secure and comfortable fit during intense workouts.

Image: The ultra-lightweight design (27g) provides a comfortable, barely-there feel.

Bateria de longa duração

A premium 170mAh lithium-ion battery provides up to 8 hours of continuous music playback on a full charge, ideal for daily workouts and extended use.

Image: Enjoy up to 8 hours of continuous music with the long-lasting battery.

Tecnologia de Condução óssea

This technology transmits sound through your bones, delivering superior 360° panoramic sound with enhanced clarity and reproduction, without blocking your ear canals.

Image: Bone conduction technology delivers sound directly through your cheekbones.

Multi-Sport Use

Designed for sports enthusiasts, these bone conduction headphones are perfect for running, swimming, cycling, and any other athletic activity.

Image: Versatile for various activities including running, driving, swimming, and working.

Configurar

Carregando os fones de ouvido

Connect the magnetic charging cable to the charging port on the headphones and plug the USB end into a compatible power source. The LED indicator will show charging status. A full charge takes approximately 2 hours.

Usando os fones de ouvido

Place the headphones with the transducers resting on your cheekbones, just in front of your ears. The neckband should rest comfortably behind your head. Adjust for a secure fit.

Emparelhamento Bluetooth

1. Pressione e segure o botão Liga/Desliga por 3 a 5 segundos até que o indicador LED pisque em azul e vermelho, indicando o modo de emparelhamento.
2. Enable Bluetooth on your device (smartphone, tablet, etc.) and search for 'LOBKIN X18'.
3. Select 'LOBKIN X18' to connect. The LED will turn solid blue when successfully paired.

Switching to MP3 Mode

Double-click the Power button to switch between Bluetooth mode and MP3 player mode. When in MP3 mode, you can play music stored on the internal 32GB memory.

Instruções de operação

Funções dos botões

Imagem: Detalhada view of the control buttons and their respective functions.

• Botão de energia:
  - Press once: Play/Pause music, Answer/End call, Activate voice assistant.
  - Press and hold for 2 seconds: Reject call.
  - Press and hold for 3-5 seconds: Power On/Off.
  - Double-click: Switch between MP3 and Bluetooth modes.
• Botão para diminuir o volume (-):
  - Press once: Decrease volume.
  - Press and hold for 2 seconds: Previous song.
• Botão de aumentar o volume (+):
  - Press once: Increase volume.
  - Press and hold for 2 seconds: Next song.

Manutenção

• After use, especially after swimming or intense workouts, gently wipe the headphones with a soft, dry cloth.
• Ensure the charging port is dry before connecting the magnetic charging cable to prevent damage.
• Guarde os fones de ouvido em local fresco e seco, longe da luz solar direta e de temperaturas extremas.
• Avoid bending or twisting the neckband excessively to maintain its durability.

Solução de problemas

• Sem energia: Certifique-se de que os fones de ouvido estejam totalmente carregados.
• Sem som: Check volume levels on both the headphones and your connected device. Ensure the headphones are properly paired via Bluetooth or in MP3 mode.
• Problemas de emparelhamento: Make sure the headphones are in pairing mode (flashing blue/red LED). Turn off and on Bluetooth on your device, then try pairing again.
• MP3 Not Playing: Ensure the headphones are in MP3 mode. Check if audio files are properly loaded onto the 32GB internal memory.
• Problemas de qualidade de som: Ensure the transducers are correctly positioned on your cheekbones.

Especificações

Garantia e Suporte

The LOBKIN X18 Bone Conduction Headphones come with a 1-year manufacturer's warranty. For any support inquiries, troubleshooting assistance, or warranty claims, please refer to the contact information provided in your warranty card or visit the official LOBKIN website.
