1. Introdução
The Newmowa Dual USB Charger is designed for efficient and convenient charging of Canon NB-13L camera batteries. This charger allows you to power two batteries simultaneously, ensuring your camera is always ready for use. Its compact design and versatile USB input make it ideal for travel and various charging environments.
Compatible Battery Models: Canon NB-13L
Compatible Camera Models: Canon PowerShot G5X, G7X, G7 X Mark II, G9X, G9 X Mark II, G1 X Mark III, SX620 HS, SX720 HS, SX730 HS
2. Conteúdo da embalagem
- 1 x Newmowa Dual USB Charger
- 1 x Cabo Micro USB
3. Instruções de configuração
Follow these steps to set up your Newmowa Dual USB Charger:
- Conecte o carregador: Insert the micro USB cable into the charger's input port.
- Conecte à fonte de alimentação: Connect the other end of the USB cable to a compatible 5V 2A USB power source. This can be a USB wall charger, car charger, power bank, or a laptop's USB port.
- Insira as baterias: Carefully insert one or two Canon NB-13L batteries into the charging slots of the charger, ensuring correct orientation.
4. Instruções de operação
The Newmowa Dual USB Charger is designed for simple and intuitive operation:
- Indicadores de status de carregamento: Each charging slot has an independent LED indicator.
- When a battery is charging, the corresponding LED will illuminate VERMELHO.
- Once the battery is fully charged, the LED will turn VERDE.
- The charger can charge one or two batteries simultaneously. Each battery's charging status is monitored independently.
5. Manutenção
Para garantir a longevidade e o desempenho ideal do seu carregador, siga estas orientações de manutenção:
- Keep the charger clean and dry. Avoid exposure to moisture, dust, and dirt.
- Do not store the charger in extremely hot or cold environments.
- Clean the charging contacts periodically with a dry, soft cloth to ensure good connection.
- Evite deixar o carregador cair ou submetê-lo a impactos fortes.
6. Solução De Problemas
Se você tiver problemas com seu carregador, consulte os problemas e soluções comuns a seguir:
| Problema | Possível causa | Solução |
|---|---|---|
| Charger LEDs do not light up. | No power supply; faulty cable; incorrect battery insertion. | Check USB power source connection. Try a different USB cable. Ensure batteries are inserted correctly. |
| Battery not charging (LED remains off or green immediately). | Battery not making proper contact; battery already full; faulty battery. | Re-insert battery, ensuring good contact. Test with a different battery. If the battery is known to be depleted and still shows green, the battery or charger may be faulty. |
| Carregamento lento. | Insufficient power input. | Ensure your USB power source provides at least 5V 2A output. Some laptop USB ports may provide lower current. |
7. Especificações
| Recurso | Detalhe |
|---|---|
| Número do modelo | CHG-NB13L-USB |
| Entrada | 5V 2A |
| Saída | 8.4V 600mA*2 |
| Dimensões | 3.07 x 2.99 x 2.13 polegadas |
| Peso do item | 1.76 onças (50 gramas) |
| Certificações | CE, FCC |
8. Informações de segurança
Please read and adhere to the following safety precautions to prevent damage to the charger, batteries, or personal injury:
- Não desmonte ou modifique o carregador.
- Keep the charger away from water, moisture, and high humidity.
- Avoid exposing the charger to direct sunlight or high temperatures.
- Do not use the charger if it appears damaged or has been dropped.
- This charger is equipped with multiple circuit protections, including over-charging, short-circuit, high-temperature, and surge protection. It is constructed with high-quality, fire-resistant materials.
- Use only compatible batteries (Canon NB-13L) with this charger.
- Mantenha fora do alcance de crianças.
