1. Introdução e Produto Acimaview
Thank you for choosing the Flyrivergo YZM-49 Photography Turntable. This motorized rotating display stand is designed to enhance your product photography and display needs. With its robust build, versatile features, and user-friendly controls, it provides a seamless 360-degree viewing experience for various items.
This 13.7-inch (35cm) turntable can support items up to 110 lbs (50kg), making it suitable for a wide range of products, from small appliances to heavy camera gear. It features adjustable rotation speeds, multiple rotation modes, and comes with a convenient remote control for effortless operation. The built-in 3600mAh rechargeable battery ensures portability, allowing you to use it anywhere without being tethered to a power outlet.
Figura 1: Overview of the Flyrivergo YZM-49 Turntable components including the main unit, remote control, power switch, frosted platform, and non-slip feet.
2. Configuração
2.1 Desembalagem e Inspeção Inicial
Carefully remove all components from the packaging. Ensure all items listed in the package contents are present and undamaged. The package should include the turntable unit, remote control, power adapter, and a set of colorful backing plates.
2.2 Carregando a bateria
The turntable features a built-in 3600mAh rechargeable battery, providing up to 6 hours of continuous operation on a 1.5-hour charge. For optimal performance, fully charge the device before its first use, especially if it has not been used for an extended period.
- Connect the provided power adapter to the charging port on the turntable.
- Conecte o adaptador a uma tomada elétrica padrão.
- The charging indicator light will illuminate (usually red) during charging and turn green when fully charged.
Figure 2: Battery specifications and charging time for the turntable.
2.3 Attaching Backing Plates
The turntable comes with 5 double-sided colorful plates (black and white have matte/glossy finishes, other colors are glossy). Choose a plate that best suits your product and desired aesthetic. Simply place the chosen plate on top of the turntable's rotating surface.
Figure 3: Remote control functions for adjusting rotation direction, mode, and angle.
3. Instruções de operação
3.1 Ligar/Desligar
To power on the turntable, locate the power switch on the side of the unit and toggle it to the 'ON' position. To power off, toggle the switch to the 'OFF' position.
3.2 Usando o controle remoto
The remote control allows for convenient adjustment of the turntable's settings from up to 16.4 feet (5m) away. This is ideal for adjusting settings mid-shoot without disturbing your setup.
- Start/Stop Rotation: Press the play/pause button on the remote.
- Mude a direção: Use the clockwise/counterclockwise buttons to reverse the rotation.
- Ajustar velocidade: Use the speed adjustment buttons (e.g., 40-90s/rev) to increase or decrease the rotation speed.
- Select Rotation Mode: Choose between continuous rotation or intermittent rotation modes.
- Set Rotation Angle: Utilize the angle increment buttons (0.1°, 15°, 45°, 90°, 180°) for precise rotational stops, useful for capturing specific product details.
Video 1: This video demonstrates the various rotation modes and speed adjustments available with the remote control for the Flyrivergo YZM-49 turntable.
Video 2: A helpful tip on effectively using the remote control with the Flyrivergo YZM-49 turntable for precise adjustments.
4. Manutenção
4.1 Limpeza
To maintain the appearance and functionality of your turntable, regularly wipe the surface with a soft, dry cloth. For stubborn marks, a slightly damp Pode-se usar um pano e secar imediatamente. Evite produtos de limpeza abrasivos ou solventes.
4.2 Armazenamento
When not in use, store the turntable in a cool, dry place away from direct sunlight and extreme temperatures. If storing for an extended period, ensure the battery is partially charged (around 50%) to prolong its lifespan.
5. Solução De Problemas
- A plataforma giratória não está girando:
- Certifique-se de que o interruptor de alimentação esteja na posição 'LIGADO'.
- Check if the battery is charged. If not, connect the power adapter.
- Verify that the remote control batteries are functional and the remote is within range.
- O controle remoto não responde:
- Substitua as pilhas do controle remoto.
- Ensure there are no obstructions between the remote and the turntable.
- Confirm the turntable is powered on.
- Unusual noise or shaking:
- Ensure the product placed on the turntable does not exceed the maximum weight capacity (110 lbs / 50kg).
- Distribute the weight evenly on the turntable surface.
- Check for any foreign objects obstructing the rotation mechanism.
Figure 4: The turntable features anti-shake and non-slip properties for stable operation.
Figure 5: Noise level comparison, indicating the turntable operates quietly at ≤50db.
6. Especificações
| Recurso | Detalhe |
|---|---|
| Número do modelo | YZM-49 |
| Marca | Flyrivergo |
| Material | Plástico ABS |
| Cor | Preto |
| Diâmetro do item | 13.7 polegadas (35 cm) |
| Capacidade Máxima de Carga | lbs 110 (50kg) |
| Velocidade de rotação | 40-90 seconds per revolution (adjustable) |
| Bateria | 3600mAh Lithium Ion (rechargeable, included) |
| Tempo de carregamento | Aproximadamente 1.5 horas |
| Tempo de trabalho contínuo | Até 6 horas |
| Nível de ruído | ≤50 dB |
| Alcance do controle remoto | 16.4 pés (5m) |
| Rotation Angle Increments | 0.1°, 15°, 45°, 90°, 180° |
| Dimensões da embalagem | 16 x 15 x 4 polegadas |
| Peso do item | 4.79 libras (2.18 kg) |
7. Garantia e suporte
The Flyrivergo YZM-49 Photography Turntable comes with a Garantia oficial de 1 anos covering missing parts or non-functional issues. For any technical assistance or inquiries, 24/7 online technical guidance is available. Our product also includes basic overload protection for safe daily use.
Please refer to the contact information provided with your purchase for customer support details.
